It's a low-level object, used to implement high-level objects such as Gtk::Widget and Gtk::Window on the GTK+ level. A Gtk::Window is a toplevel window, the thing a user might think of as a "window" with a titlebar and so on; a Gtk::Window may contain many Gdk::Windows. For example, each Gtk::Button has a Gdk::Window associated with it.
Public Member Functions | |
| void | add_filter (GdkFilterFunc function, gpointer data) |
| Adds an event filter to window , allowing you to intercept events before they reach GDK. | |
| void | begin_move_drag (int button, int root_x, int root_y, guint32 timestamp) |
| Begins a window move operation (for a toplevel window). | |
| void | begin_paint_rect (Rectangle& rectangle) |
| A convenience wrapper around gdk_window_begin_paint_region() which creates a rectangular region for you. | |
| void | begin_paint_region (const Region& region) |
| Indicates that you are beginning the process of redrawing region . | |
| void | begin_resize_drag (WindowEdge edge, int button, int root_x, int root_y, guint32 timestamp) |
| Begins a window resize operation (for a toplevel window). | |
| void | clear () |
| Clears an entire window to the background color or background pixmap. | |
| void | clear_area (int x, int y, int width, int height) |
| Clears an area of window to the background color or background pixmap. | |
| void | clear_area_e (int x, int y, int width, int height) |
| Like gdk_window_clear_area(), but also generates an expose event for the cleared area. | |
| void | configure_finished () |
| Signal to the window system that the application has finished handling Configure events it has received. | |
| void | deiconify () |
| Attempt to deiconify (unminimize) window . | |
| void | enable_synchronized_configure () |
| Indicates that the application will cooperate with the window system in synchronizing the window repaint with the window manager during resizing operations. | |
| void | end_paint () |
| Indicates that the backing store created by the most recent call to gdk_window_begin_paint_region() should be copied onscreen and deleted, leaving the next-most-recent backing store or no backing store at all as the active paint region. | |
| void | focus (guint32 timestamp) |
| Sets keyboard focus to window . | |
| void | freeze_updates () |
| Temporarily freezes a window such that it won't receive expose events. | |
| void | fullscreen () |
| Moves the window into fullscreen mode. | |
| Glib::ListHandle< Glib::RefPtr< const Window > > | get_children () const |
| Gets the list of children of window known to GDK. | |
| Glib::ListHandle< Glib::RefPtr< Window > > | get_children () |
| Gets the list of children of window known to GDK. | |
| bool | get_decorations (WMDecoration& decorations) const |
| Returns the decorations set on the GdkWindow with gdk_window_set_decorations. | |
| EventMask | get_events () const |
| Gets the event mask for window . | |
| void | get_frame_extents (Rectangle& rect) |
| Obtains the bounding box of the window, including window manager titlebar/borders if any. | |
| void | get_geometry (int& x, int& y, int& width, int& height, int& depth) const |
Any of the return location arguments to this function may be 0, if you aren't interested in getting the value of that field. | |
| Glib::RefPtr<const Window> | get_group () const |
| Returns the group leader window for window . | |
| Glib::RefPtr<Window> | get_group () |
| Returns the group leader window for window . | |
| void | get_internal_paint_info (Glib::RefPtr<Drawable>& real_drawable, int& x_offset, int& y_offset) const |
| int | get_origin (int& x, int& y) const |
| Obtains the position of a window in root window coordinates. | |
| Glib::RefPtr<const Window> | get_parent () const |
| Obtains the parent of window , as known to GDK. | |
| Glib::RefPtr<Window> | get_parent () |
| Obtains the parent of window , as known to GDK. | |
| Glib::RefPtr<Window> | get_pointer (int& x, int& y, ModifierType& mask) |
| Obtains the current pointer position and modifier state. | |
| void | get_position (int& x, int& y) const |
| Obtains the position of the window as reported in the most-recently-processed Gdk::EventConfigure. | |
| void | get_root_origin (int& x, int& y) const |
| Obtains the top-left corner of the window manager frame in root window coordinates. | |
| WindowState | get_state () const |
| Gets the bitwise OR of the currently active window state flags, from the Gdk::WindowState enumeration. | |
| Glib::RefPtr<const Window> | get_toplevel () const |
| Gets the toplevel window that's an ancestor of window . | |
| Glib::RefPtr<Window> | get_toplevel () |
| Gets the toplevel window that's an ancestor of window . | |
| Region | get_update_area () |
| Transfers ownership of the update area from window to the caller of the function. | |
| void | get_user_data (gpointer* data) |
| Retrieves the user data for window , which is normally the widget that window belongs to. | |
| WindowType | get_window_type () const |
| Gets the type of the window. | |
| const GdkWindow* | gobj () const |
| Provides access to the underlying C GObject. | |
| GdkWindow* | gobj () |
| Provides access to the underlying C GObject. | |
| GdkWindow* | gobj_copy () |
| Provides access to the underlying C instance. The caller is responsible for unrefing it. Use when directly setting fields in structs. | |
| void | hide () |
| For toplevel windows, withdraws them, so they will no longer be known to the window manager; for all windows, unmaps them, so they won't be displayed. | |
| void | iconify () |
| Asks to iconify (minimize) window . | |
| void | invalidate_rect (const Rectangle& rect, bool invalidate_children) |
| A convenience wrapper around gdk_window_invalidate_region() which invalidates a rectangular region. | |
| void | invalidate_region (const Region& region, bool invalidate_children=true) |
| Adds region to the update area for window . | |
| bool | is_viewable () const |
| Check if the window and all ancestors of the window are mapped. | |
| bool | is_visible () const |
| Checks whether the window has been mapped (with gdk_window_show() or gdk_window_show_unraised()). | |
| GrabStatus | keyboard_grab (bool owner_events, guint32 timestamp) |
| void | lower () |
| Lowers window to the bottom of the Z-order (stacking order), so that other windows with the same parent window appear above window . | |
| void | maximize () |
| Maximizes the window. | |
| void | merge_child_shapes () |
| Merges the shape masks for any child windows into the shape mask for window . | |
| void | move (int x, int y) |
| Repositions a window relative to its parent window. | |
| void | move_region (const Region& region, int dx, int dy) |
| Move the part of window indicated by region by dy pixels in the Y direction and dx pixels in the X direction. | |
| void | move_resize (int x, int y, int width, int height) |
| Equivalent to calling gdk_window_move() and gdk_window_resize(), except that both operations are performed at once, avoiding strange visual effects. | |
| GrabStatus | pointer_grab (bool owner_events, EventMask event_mask, guint32 timestamp) |
| Grabs the pointer to a specific window. | |
| GrabStatus | pointer_grab (bool owner_events, EventMask event_mask, const Cursor& cursor, guint32 timestamp) |
| Grabs the pointer to a specific window. | |
| GrabStatus | pointer_grab (bool owner_events, EventMask event_mask, const Glib::RefPtr<const Window>& confine_to, const Cursor& cursor, guint32 time_) |
| void | process_updates (bool update_children) |
| Sends one or more expose events to window . | |
| void | raise () |
| Raises window to the top of the Z-order (stacking order), so that other windows with the same parent window appear below window . | |
| void | register_dnd () |
| void | remove_filter (GdkFilterFunc function, gpointer data) |
| Remove a filter previously added with gdk_window_add_filter(). | |
| void | reparent (const Glib::RefPtr<Window>& new_parent, int x, int y) |
| Reparents window into the given new_parent . | |
| void | resize (int width, int height) |
| Resizes window ; for toplevel windows, asks the window manager to resize the window. | |
| void | scroll (int dx, int dy) |
| Scroll the contents of window , both pixels and children, by the given amount. | |
| void | set_accept_focus (bool accept_focus=true) |
Setting accept_focus to false hints the desktop environment that the window doesn't want to receive input focus. | |
| void | set_back_pixmap (const Glib::RefPtr<Pixmap>& pixmap, bool parent_relative) |
| Sets the background pixmap of window . | |
| void | set_background (const Color& color) |
| Sets the background color of window . | |
| void | set_child_shapes () |
| Sets the shape mask of window to the union of shape masks for all children of window , ignoring the shape mask of window itself. | |
| void | set_cursor () |
| Use the parent window's cursor. | |
| void | set_cursor (const Cursor& cursor) |
| Sets the mouse pointer for a Gdk::Window. | |
| void | set_decorations (WMDecoration decorations) |
| "Decorations" are the features the window manager adds to a toplevel Gdk::Window. | |
| void | set_events (EventMask event_mask) |
| The event mask for a window determines which events will be reported for that window. | |
| void | set_focus_on_map (bool focus_on_map) |
Setting focus_on_map to false hints the desktop environment that the window doesn't want to receive input focus when it is mapped. | |
| void | set_functions (WMFunction functions) |
| This function isn't really good for much. | |
| void | set_geometry_hints (const Geometry& geometry, WindowHints geom_mask) |
| Sets the geometry hints for window . | |
| void | set_group (const Glib::RefPtr<Window>& leader) |
| Sets the group leader window for window . | |
| void | set_icon (const Glib::RefPtr<Window>& icon_window, const Glib::RefPtr<Pixmap>& pixmap) |
| void | set_icon (const Glib::RefPtr<Window>& icon_window, const Glib::RefPtr<Pixmap>& pixmap, const Glib::RefPtr<Bitmap>& mask) |
| Sets the icon of window as a pixmap or window. | |
| void | set_icon_list (const Glib::ListHandle<Glib::RefPtr<Gdk::Pixbuf>>& pixbufs) |
| Sets a list of icons for the window. | |
| void | set_icon_name (const Glib::ustring& name) |
| Windows may have a name used while minimized, distinct from the name they display in their titlebar. | |
| void | set_keep_above (bool setting=true) |
| Set if window must be kept above other windows. | |
| void | set_keep_below (bool setting=true) |
| Set if window must be kept below other windows. | |
| void | set_modal_hint (bool modal=true) |
| The application can use this hint to tell the window manager that a certain window has modal behaviour. | |
| void | set_override_redirect (bool override_redirect=true) |
| An override redirect window is not under the control of the window manager. | |
| void | set_role (const Glib::ustring& role) |
| When using GTK+, typically you should use gtk_window_set_role() instead of this low-level function. | |
| void | set_skip_pager_hint (bool skips_pager=true) |
| Toggles whether a window should appear in a pager (workspace switcher, or other desktop utility program that displays a small thumbnail representation of the windows on the desktop). | |
| void | set_skip_taskbar_hint (bool skips_taskbar=true) |
| Toggles whether a window should appear in a task list or window list. | |
| bool | set_static_gravities (bool use_static=true) |
| Set the bit gravity of the given window to static, and flag it so all children get static subwindow gravity. | |
| void | set_title (const Glib::ustring& title) |
| Sets the title of a toplevel window, to be displayed in the titlebar. | |
| void | set_transient_for (const Glib::RefPtr<Window>& parent) |
| Indicates to the window manager that window is a transient dialog associated with the application window parent . | |
| void | set_type_hint (WindowTypeHint hint) |
| The application can use this call to provide a hint to the window manager about the functionality of a window. | |
| void | set_urgency_hint (bool urgent=true) |
| Toggles whether a window needs the user's urgent attention. | |
| void | set_user_data (gpointer user_data) |
| For most purposes this function is deprecated in favor of Glib::object_set_data(). | |
| void | shape_combine_mask (const Glib::RefPtr<Bitmap>& mask, int x, int y) |
| Applies a shape mask to window . | |
| void | shape_combine_region (const Region& shape_region, int offset_x, int offset_y) |
| Makes pixels in window outside shape_region be transparent, so that the window may be nonrectangular. | |
| void | show () |
| Like gdk_window_show_unraised(), but also raises the window to the top of the window stack (moves the window to the front of the Z-order). | |
| void | show_unraised () |
| Shows a Gdk::Window onscreen, but does not modify its stacking order. | |
| void | stick () |
| "Pins" a window such that it's on all workspaces and does not scroll with viewports, for window managers that have scrollable viewports. | |
| void | thaw_updates () |
| Thaws a window frozen with Gdk::Window::freeze_updates(). | |
| void | unfullscreen () |
| Moves the window out of fullscreen mode. | |
| void | unmaximize () |
| Unmaximizes the window. | |
| void | unset_icon () |
| void | unset_shape_combine_mask () |
| void | unstick () |
| Reverse operation for gdk_window_stick(); see gdk_window_stick(), and gtk_window_unstick(). | |
| void | withdraw () |
| Withdraws a window (unmaps it and asks the window manager to forget about it). | |
| virtual | ~Window () |
Static Public Member Functions | |
| static void | constrain_size (const Geometry& geometry, guint flags, int width, int height, int& new_width, int& new_height) |
| Constrains a desired width and height according to a set of geometry hints (such as minimum and maximum size). | |
| static Glib::RefPtr<Window> | create (const Glib::RefPtr<Window>& parent, GdkWindowAttr* attributes, int attributes_mask) |
| static Glib::ListHandle< Glib::RefPtr< Window > > | get_toplevels () |
| Obtains a list of all toplevel windows known to GDK on the default screen (see gdk_window_get_toplevels_for_screen()). | |
| static void | keyboard_ungrab (guint32 timestamp) |
| Ungrabs the keyboard, if it is grabbed by this application. | |
| static void | pointer_ungrab (guint32 timestamp) |
| Ungrabs the pointer, if it is grabbed by this application. | |
| static void | process_all_updates () |
| Calls gdk_window_process_updates() for all windows (see Gdk::Window) in the application. | |
| static void | set_debug_updates (bool setting=true) |
| With update debugging enabled, calls to gdk_window_invalidate_region() clear the invalidated region of the screen to a noticeable color, and GDK pauses for a short time before sending exposes to windows during gdk_window_process_updates(). | |
| static void | set_sm_client_id (const Glib::ustring& sm_client_id) |
Sets the SM_CLIENT_ID property on the application's leader window so that the window manager can save the application's state using the X11R6 ICCCM session management protocol. | |
| static void | unset_sm_client_id () |
Protected Member Functions | |
| Window (const Glib::RefPtr<Window>& parent, GdkWindowAttr* attributes, int attributes_mask) | |
Related Functions | |
| (Note that these are not member functions.) | |
| Glib::RefPtr<Gdk::Window> | wrap (GdkWindowObject* object, bool take_copy=false) |
| A Glib::wrap() method for this object. | |
| virtual Gdk::Window::~Window | ( | ) | [virtual] |
| Gdk::Window::Window | ( | const Glib::RefPtr<Window>& | parent, | |
| GdkWindowAttr * | attributes, | |||
| int | attributes_mask | |||
| ) | [protected] |
| void Gdk::Window::add_filter | ( | GdkFilterFunc | function, | |
| gpointer | data | |||
| ) |
Adds an event filter to window , allowing you to intercept events before they reach GDK.
This is a low-level operation and makes it easy to break GDK and/or GTK+, so you have to know what you're doing. Pass 0 for window to get all events for all windows, instead of events for a specific window.
| function | Filter callback. | |
| data | Data to pass to filter callback. |
| void Gdk::Window::begin_move_drag | ( | int | button, | |
| int | root_x, | |||
| int | root_y, | |||
| guint32 | timestamp | |||
| ) |
Begins a window move operation (for a toplevel window).
You might use this function to implement a "window move grip," for example. The function works best with window managers that support the Extended Window Manager Hints, but has a fallback implementation for other window managers.
| button | The button being used to drag. | |
| root_x | Root window X coordinate of mouse click that began the drag. | |
| root_y | Root window Y coordinate of mouse click that began the drag. | |
| timestamp | Timestamp of mouse click that began the drag. |
| void Gdk::Window::begin_paint_rect | ( | Rectangle& | rectangle | ) |
A convenience wrapper around gdk_window_begin_paint_region() which creates a rectangular region for you.
See gdk_window_begin_paint_region() for details.
| rectangle | Rectangle you intend to draw to. |
| void Gdk::Window::begin_paint_region | ( | const Region& | region | ) |
Indicates that you are beginning the process of redrawing region .
A backing store (offscreen buffer) large enough to contain region will be created. The backing store will be initialized with the background color or background pixmap for window . Then, all drawing operations performed on window will be diverted to the backing store. When you call gdk_window_end_paint(), the backing store will be copied to window , making it visible onscreen. Only the part of window contained in region will be modified; that is, drawing operations are clipped to region .
The net result of all this is to remove flicker, because the user sees the finished product appear all at once when you call gdk_window_end_paint(). If you draw to window directly without calling gdk_window_begin_paint_region(), the user may see flicker as individual drawing operations are performed in sequence. The clipping and background-initializing features of gdk_window_begin_paint_region() are conveniences for the programmer, so you can avoid doing that work yourself.
When using GTK+, the widget system automatically places calls to gdk_window_begin_paint_region() and gdk_window_end_paint() around emissions of the expose_event signal. That is, if you're writing an expose event handler, you can assume that the exposed area in Gdk::EventExpose has already been cleared to the window background, is already set as the clip region, and already has a backing store. Therefore in most cases, application code need not call gdk_window_begin_paint_region(). (You can disable the automatic calls around expose events on a widget-by-widget basis by calling gtk_widget_set_double_buffered().)
If you call this function multiple times before calling the matching gdk_window_end_paint(), the backing stores are pushed onto a stack. gdk_window_end_paint() copies the topmost backing store onscreen, subtracts the topmost region from all other regions in the stack, and pops the stack. All drawing operations affect only the topmost backing store in the stack. One matching call to gdk_window_end_paint() is required for each call to gdk_window_begin_paint_region().
| region | Region you intend to draw to. |
| void Gdk::Window::begin_resize_drag | ( | WindowEdge | edge, | |
| int | button, | |||
| int | root_x, | |||
| int | root_y, | |||
| guint32 | timestamp | |||
| ) |
Begins a window resize operation (for a toplevel window).
You might use this function to implement a "window resize grip," for example; in fact Gtk::Statusbar uses it. The function works best with window managers that support the Extended Window Manager Hints, but has a fallback implementation for other window managers.
| edge | The edge or corner from which the drag is started. | |
| button | The button being used to drag. | |
| root_x | Root window X coordinate of mouse click that began the drag. | |
| root_y | Root window Y coordinate of mouse click that began the drag. | |
| timestamp | Timestamp of mouse click that began the drag (use gdk_event_get_time()). |
| void Gdk::Window::clear | ( | ) |
Clears an entire window to the background color or background pixmap.
| void Gdk::Window::clear_area | ( | int | x, | |
| int | y, | |||
| int | width, | |||
| int | height | |||
| ) |
Clears an area of window to the background color or background pixmap.
| x | X coordinate of rectangle to clear. | |
| y | Y coordinate of rectangle to clear. | |
| width | Width of rectangle to clear. | |
| height | Height of rectangle to clear. |
| void Gdk::Window::clear_area_e | ( | int | x, | |
| int | y, | |||
| int | width, | |||
| int | height | |||
| ) |
Like gdk_window_clear_area(), but also generates an expose event for the cleared area.
This function has a stupid name because it dates back to the mists time, pre-GDK-1.0.
| x | X coordinate of rectangle to clear. | |
| y | Y coordinate of rectangle to clear. | |
| width | Width of rectangle to clear. | |
| height | Height of rectangle to clear. |
| void Gdk::Window::configure_finished | ( | ) |
Signal to the window system that the application has finished handling Configure events it has received.
Window Managers can use this to better synchronize the frame repaint with the application. GTK+ applications will automatically call this function when appropriate.
This function can only be called if gdk_window_enable_synchronized_configure() was called previously.
| static void Gdk::Window::constrain_size | ( | const Geometry& | geometry, | |
| guint | flags, | |||
| int | width, | |||
| int | height, | |||
| int & | new_width, | |||
| int & | new_height | |||
| ) | [static] |
Constrains a desired width and height according to a set of geometry hints (such as minimum and maximum size).
| geometry | A Gdk::Geometry structure. | |
| flags | A mask indicating what portions of geometry are set. | |
| width | Desired width of window. | |
| height | Desired height of the window. | |
| new_width | Location to store resulting width. | |
| new_height | Location to store resulting height. |
| static Glib::RefPtr<Window> Gdk::Window::create | ( | const Glib::RefPtr<Window>& | parent, | |
| GdkWindowAttr * | attributes, | |||
| int | attributes_mask | |||
| ) | [static] |
| void Gdk::Window::deiconify | ( | ) |
Attempt to deiconify (unminimize) window .
On X11 the window manager may choose to ignore the request to deiconify. When using GTK+, use gtk_window_deiconify() instead of the Gdk::Window variant. Or better yet, you probably want to use gtk_window_present(), which raises the window, focuses it, unminimizes it, and puts it on the current desktop.
| void Gdk::Window::enable_synchronized_configure | ( | ) |
Indicates that the application will cooperate with the window system in synchronizing the window repaint with the window manager during resizing operations.
After an application calls this function, it must call gdk_window_configure_finished() every time it has finished all processing associated with a set of Configure events. Toplevel GTK+ windows automatically use this protocol.
On X, calling this function makes window participate in the _NET_WM_SYNC_REQUEST window manager protocol.
| void Gdk::Window::end_paint | ( | ) |
Indicates that the backing store created by the most recent call to gdk_window_begin_paint_region() should be copied onscreen and deleted, leaving the next-most-recent backing store or no backing store at all as the active paint region.
See gdk_window_begin_paint_region() for full details. It is an error to call this function without a matching gdk_window_begin_paint_region() first.
| void Gdk::Window::focus | ( | guint32 | timestamp | ) |
Sets keyboard focus to window .
In most cases, gtk_window_present() should be used on a Gtk::Window, rather than calling this function.
| timestamp | Timestamp of the event triggering the window focus. |
| void Gdk::Window::freeze_updates | ( | ) |
Temporarily freezes a window such that it won't receive expose events.
The window will begin receiving expose events again when Gdk::Window::thaw_updates() is called. If Gdk::Window::freeze_updates() has been called more than once, Gdk::Window::thaw_updates() must be called an equal number of times to begin processing exposes.
| void Gdk::Window::fullscreen | ( | ) |
Moves the window into fullscreen mode.
This means the window covers the entire screen and is above any panels or task bars.
If the window was already fullscreen, then this function does nothing.
On X11, asks the window manager to put window in a fullscreen state, if the window manager supports this operation. Not all window managers support this, and some deliberately ignore it or don't have a concept of "fullscreen"; so you can't rely on the fullscreenification actually happening. But it will happen with most standard window managers, and GDK makes a best effort to get it to happen.
| Glib::ListHandle<Glib::RefPtr<const Window>> Gdk::Window::get_children | ( | ) | const |
Gets the list of children of window known to GDK.
This function only returns children created via GDK, so for example it's useless when used with the root window; it only returns windows an application created itself.
The returned list must be freed, but the elements in the list need not be.
| Glib::ListHandle<Glib::RefPtr<Window>> Gdk::Window::get_children | ( | ) |
Gets the list of children of window known to GDK.
This function only returns children created via GDK, so for example it's useless when used with the root window; it only returns windows an application created itself.
The returned list must be freed, but the elements in the list need not be.
| bool Gdk::Window::get_decorations | ( | WMDecoration& | decorations | ) | const |
Returns the decorations set on the GdkWindow with gdk_window_set_decorations.
| decorations | The window decorations will be written here. |
true if the window has decorations set, false otherwise. | EventMask Gdk::Window::get_events | ( | ) | const |
| void Gdk::Window::get_frame_extents | ( | Rectangle& | rect | ) |
Obtains the bounding box of the window, including window manager titlebar/borders if any.
The frame position is given in root window coordinates. To get the position of the window itself (rather than the frame) in root window coordinates, use gdk_window_get_origin().
| rect | Rectangle to fill with bounding box of the window frame. |
| void Gdk::Window::get_geometry | ( | int & | x, | |
| int & | y, | |||
| int & | width, | |||
| int & | height, | |||
| int & | depth | |||
| ) | const |
Any of the return location arguments to this function may be 0, if you aren't interested in getting the value of that field.
The X and Y coordinates returned are relative to the parent window of window , which for toplevels usually means relative to the window decorations (titlebar, etc.) rather than relative to the root window (screen-size background window).
On the X11 platform, the geometry is obtained from the X server, so reflects the latest position of window ; this may be out-of-sync with the position of window delivered in the most-recently-processed Gdk::EventConfigure. gdk_window_get_position() in contrast gets the position from the most recent configure event.
<note> If window is not a toplevel, it is much better to call gdk_window_get_position() and Gdk::Drawable::get_size() instead, because it avoids the roundtrip to the X server and because Gdk::Drawable::get_size() supports the full 32-bit coordinate space, whereas gdk_window_get_geometry() is restricted to the 16-bit coordinates of X11. </note>
| x | Return location for X coordinate of window (relative to its parent). | |
| y | Return location for Y coordinate of window (relative to its parent). | |
| width | Return location for width of window. | |
| height | Return location for height of window. | |
| depth | Return location for bit depth of window. |
| Glib::RefPtr<const Window> Gdk::Window::get_group | ( | ) | const |
Returns the group leader window for window .
See gdk_window_set_group().
| Glib::RefPtr<Window> Gdk::Window::get_group | ( | ) |
Returns the group leader window for window .
See gdk_window_set_group().
| void Gdk::Window::get_internal_paint_info | ( | Glib::RefPtr<Drawable>& | real_drawable, | |
| int & | x_offset, | |||
| int & | y_offset | |||
| ) | const |
| int Gdk::Window::get_origin | ( | int & | x, | |
| int & | y | |||
| ) | const |
Obtains the position of a window in root window coordinates.
(Compare with gdk_window_get_position() and gdk_window_get_geometry() which return the position of a window relative to its parent window.)
| x | Return location for X coordinate. | |
| y | Return location for Y coordinate. |
| Glib::RefPtr<const Window> Gdk::Window::get_parent | ( | ) | const |
Obtains the parent of window , as known to GDK.
Does not query the X server; thus this returns the parent as passed to gdk_window_new(), not the actual parent. This should never matter unless you're using Xlib calls mixed with GDK calls on the X11 platform. It may also matter for toplevel windows, because the window manager may choose to reparent them.
| Glib::RefPtr<Window> Gdk::Window::get_parent | ( | ) |
Obtains the parent of window , as known to GDK.
Does not query the X server; thus this returns the parent as passed to gdk_window_new(), not the actual parent. This should never matter unless you're using Xlib calls mixed with GDK calls on the X11 platform. It may also matter for toplevel windows, because the window manager may choose to reparent them.
| Glib::RefPtr<Window> Gdk::Window::get_pointer | ( | int & | x, | |
| int & | y, | |||
| ModifierType& | mask | |||
| ) |
Obtains the current pointer position and modifier state.
The position is given in coordinates relative to window .
| x | Return location for X coordinate of pointer. | |
| y | Return location for Y coordinate of pointer. | |
| mask | Return location for modifier mask. |
0 if the window containing the pointer isn't known to GDK. | void Gdk::Window::get_position | ( | int & | x, | |
| int & | y | |||
| ) | const |
Obtains the position of the window as reported in the most-recently-processed Gdk::EventConfigure.
Contrast with gdk_window_get_geometry() which queries the X server for the current window position, regardless of which events have been received or processed.
The position coordinates are relative to the window's parent window.
| x | X coordinate of window. | |
| y | Y coordinate of window. |
| void Gdk::Window::get_root_origin | ( | int & | x, | |
| int & | y | |||
| ) | const |
Obtains the top-left corner of the window manager frame in root window coordinates.
| x | Return location for X position of window frame. | |
| y | Return location for Y position of window frame. |
| WindowState Gdk::Window::get_state | ( | ) | const |
Gets the bitwise OR of the currently active window state flags, from the Gdk::WindowState enumeration.
| Glib::RefPtr<const Window> Gdk::Window::get_toplevel | ( | ) | const |
Gets the toplevel window that's an ancestor of window .
| Glib::RefPtr<Window> Gdk::Window::get_toplevel | ( | ) |
Gets the toplevel window that's an ancestor of window .
| static Glib::ListHandle<Glib::RefPtr<Window>> Gdk::Window::get_toplevels | ( | ) | [static] |
Obtains a list of all toplevel windows known to GDK on the default screen (see gdk_window_get_toplevels_for_screen()).
A toplevel window is a child of the root window (see gdk_get_default_root_window()).
| Region Gdk::Window::get_update_area | ( | ) |
Transfers ownership of the update area from window to the caller of the function.
That is, after calling this function, window will no longer have an invalid/dirty region; the update area is removed from window and handed to you. If a window has no update area, gdk_window_get_update_area() returns 0. You are responsible for calling gdk_region_destroy() on the returned region if it's non-0.
| void Gdk::Window::get_user_data | ( | gpointer * | data | ) |
Retrieves the user data for window , which is normally the widget that window belongs to.
See gdk_window_set_user_data().
| data | Return location for user data. |
| WindowType Gdk::Window::get_window_type | ( | ) | const |
| const GdkWindow* Gdk::Window::gobj | ( | ) | const [inline] |
| GdkWindow* Gdk::Window::gobj | ( | ) | [inline] |
| GdkWindow* Gdk::Window::gobj_copy | ( | ) |
Provides access to the underlying C instance. The caller is responsible for unrefing it. Use when directly setting fields in structs.
Reimplemented from Gdk::Drawable.
| void Gdk::Window::hide | ( | ) |
For toplevel windows, withdraws them, so they will no longer be known to the window manager; for all windows, unmaps them, so they won't be displayed.
Normally done automatically as part of gtk_widget_hide().
| void Gdk::Window::iconify | ( | ) |
Asks to iconify (minimize) window .
The window manager may choose to ignore the request, but normally will honor it. Using gtk_window_iconify() is preferred, if you have a Gtk::Window widget.
This function only makes sense when window is a toplevel window.
| void Gdk::Window::invalidate_rect | ( | const Rectangle& | rect, | |
| bool | invalidate_children | |||
| ) |
A convenience wrapper around gdk_window_invalidate_region() which invalidates a rectangular region.
See gdk_window_invalidate_region() for details.
| rect | Rectangle to invalidate. | |
| invalidate_children | Whether to also invalidate child windows. |
| void Gdk::Window::invalidate_region | ( | const Region& | region, | |
| bool | invalidate_children = true | |||
| ) |
Adds region to the update area for window .
The update area is the region that needs to be redrawn, or "dirty region." The call gdk_window_process_updates() sends one or more expose events to the window, which together cover the entire update area. An application would normally redraw the contents of window in response to those expose events.
GDK will call gdk_window_process_all_updates() on your behalf whenever your program returns to the main loop and becomes idle, so normally there's no need to do that manually, you just need to invalidate regions that you know should be redrawn.
The invalidate_children parameter controls whether the region of each child window that intersects region will also be invalidated. If false, then the update area for child windows will remain unaffected. See gdk_window_invalidate_maybe_recurse if you need fine grained control over which children are invalidated.
| region | A Gdk::Region. | |
| invalidate_children | true to also invalidate child windows. |
| bool Gdk::Window::is_viewable | ( | ) | const |
Check if the window and all ancestors of the window are mapped.
(This is not necessarily "viewable" in the X sense, since we only check as far as we have GDK window parents, not to the root window.)
true if the window is viewable. | bool Gdk::Window::is_visible | ( | ) | const |
Checks whether the window has been mapped (with gdk_window_show() or gdk_window_show_unraised()).
true if the window is mapped. | GrabStatus Gdk::Window::keyboard_grab | ( | bool | owner_events, | |
| guint32 | timestamp | |||
| ) |
| static void Gdk::Window::keyboard_ungrab | ( | guint32 | timestamp | ) | [static] |
Ungrabs the keyboard, if it is grabbed by this application.
| timestamp | A timestamp from a Gdk::Event, or Gdk::CURRENT_TIME if no timestamp is available. |
| void Gdk::Window::lower | ( | ) |
Lowers window to the bottom of the Z-order (stacking order), so that other windows with the same parent window appear above window .
This is true whether or not the other windows are visible.
If window is a toplevel, the window manager may choose to deny the request to move the window in the Z-order, gdk_window_lower() only requests the restack, does not guarantee it.
Note that gdk_window_show() raises the window again, so don't call this function before gdk_window_show(). (Try gdk_window_show_unraised().)
| void Gdk::Window::maximize | ( | ) |
Maximizes the window.
If the window was already maximized, then this function does nothing.
On X11, asks the window manager to maximize window , if the window manager supports this operation. Not all window managers support this, and some deliberately ignore it or don't have a concept of "maximized"; so you can't rely on the maximization actually happening. But it will happen with most standard window managers, and GDK makes a best effort to get it to happen.
On Windows, reliably maximizes the window.
| void Gdk::Window::merge_child_shapes | ( | ) |
Merges the shape masks for any child windows into the shape mask for window .
i.e. the union of all masks for window and its children will become the new mask for window . See gdk_window_shape_combine_mask().
This function is distinct from gdk_window_set_child_shapes() because it includes window 's shape mask in the set of shapes to be merged.
| void Gdk::Window::move | ( | int | x, | |
| int | y | |||
| ) |
Repositions a window relative to its parent window.
For toplevel windows, window managers may ignore or modify the move; you should probably use gtk_window_move() on a Gtk::Window widget anyway, instead of using GDK functions. For child windows, the move will reliably succeed.
If you're also planning to resize the window, use gdk_window_move_resize() to both move and resize simultaneously, for a nicer visual effect.
| x | X coordinate relative to window's parent. | |
| y | Y coordinate relative to window's parent. |
| void Gdk::Window::move_region | ( | const Region& | region, | |
| int | dx, | |||
| int | dy | |||
| ) |
Move the part of window indicated by region by dy pixels in the Y direction and dx pixels in the X direction.
The portions of region that not covered by the new position of region are invalidated.
Child windows are not moved.
| region | The Gdk::Region to move. | |
| dx | Amount to move in the X direction. | |
| dy | Amount to move in the Y direction. |
| void Gdk::Window::move_resize | ( | int | x, | |
| int | y, | |||
| int | width, | |||
| int | height | |||
| ) |
Equivalent to calling gdk_window_move() and gdk_window_resize(), except that both operations are performed at once, avoiding strange visual effects.
(i.e. the user may be able to see the window first move, then resize, if you don't use gdk_window_move_resize().)
| x | New X position relative to window's parent. | |
| y | New Y position relative to window's parent. | |
| width | New width. | |
| height | New height. |
| GrabStatus Gdk::Window::pointer_grab | ( | bool | owner_events, | |
| EventMask | event_mask, | |||
| guint32 | timestamp | |||
| ) |
Grabs the pointer to a specific window.
Requires a corresponding call to pointer_ungrab().
Arguments:
| owner_events | Specifies whether events will be reported as is, or relative to the window. | |
| event_mask | Masks only interesting events. | |
| timestamp | Specifies the time. |
| GrabStatus Gdk::Window::pointer_grab | ( | bool | owner_events, | |
| EventMask | event_mask, | |||
| const Cursor& | cursor, | |||
| guint32 | timestamp | |||
| ) |
Grabs the pointer to a specific window.
Requires a corresponding call to pointer_ungrab().
Arguments:
| owner_events | Specifies whether events will be reported as is, or relative to the window. | |
| event_mask | Masks only interesting events. | |
| cursor | Changes the cursor for the duration of the grab. | |
| timestamp | Specifies the time. |
| GrabStatus Gdk::Window::pointer_grab | ( | bool | owner_events, | |
| EventMask | event_mask, | |||
| const Glib::RefPtr<const Window>& | confine_to, | |||
| const Cursor& | cursor, | |||
| guint32 | time_ | |||
| ) |
| static void Gdk::Window::pointer_ungrab | ( | guint32 | timestamp | ) | [static] |
Ungrabs the pointer, if it is grabbed by this application.
| timestamp | A timestamp from a Gdk::Event, or Gdk::CURRENT_TIME if no timestamp is available. |
| static void Gdk::Window::process_all_updates | ( | ) | [static] |
Calls gdk_window_process_updates() for all windows (see Gdk::Window) in the application.
| void Gdk::Window::process_updates | ( | bool | update_children | ) |
Sends one or more expose events to window .
The areas in each expose event will cover the entire update area for the window (see gdk_window_invalidate_region() for details). Normally GDK calls gdk_window_process_all_updates() on your behalf, so there's no need to call this function unless you want to force expose events to be delivered immediately and synchronously (vs. the usual case, where GDK delivers them in an idle handler). Occasionally this is useful to produce nicer scrolling behavior, for example.
| update_children | Whether to also process updates for child windows. |
| void Gdk::Window::raise | ( | ) |
Raises window to the top of the Z-order (stacking order), so that other windows with the same parent window appear below window .
This is true whether or not the windows are visible.
If window is a toplevel, the window manager may choose to deny the request to move the window in the Z-order, gdk_window_raise() only requests the restack, does not guarantee it.
| void Gdk::Window::register_dnd | ( | ) |
| void Gdk::Window::remove_filter | ( | GdkFilterFunc | function, | |
| gpointer | data | |||
| ) |
Remove a filter previously added with gdk_window_add_filter().
| function | Previously-added filter function. | |
| data | User data for previously-added filter function. |
| void Gdk::Window::reparent | ( | const Glib::RefPtr<Window>& | new_parent, | |
| int | x, | |||
| int | y | |||
| ) |
Reparents window into the given new_parent .
The window being reparented will be unmapped as a side effect.
| new_parent | New parent to move window into. | |
| x | X location inside the new parent. | |
| y | Y location inside the new parent. |
| void Gdk::Window::resize | ( | int | width, | |
| int | height | |||
| ) |
Resizes window ; for toplevel windows, asks the window manager to resize the window.
The window manager may not allow the resize. When using GTK+, use gtk_window_resize() instead of this low-level GDK function.
Windows may not be resized below 1x1.
If you're also planning to move the window, use gdk_window_move_resize() to both move and resize simultaneously, for a nicer visual effect.
| width | New width of the window. | |
| height | New height of the window. |
| void Gdk::Window::scroll | ( | int | dx, | |
| int | dy | |||
| ) |
Scroll the contents of window , both pixels and children, by the given amount.
window itself does not move. Portions of the window that the scroll operation brings in from offscreen areas are invalidated. The invalidated region may be bigger than what would strictly be necessary. (For X11, a minimum area will be invalidated if the window has no subwindows, or if the edges of the window's parent do not extend beyond the edges of the window. In other cases, a multi-step process is used to scroll the window which may produce temporary visual artifacts and unnecessary invalidations.)
| dx | Amount to scroll in the X direction. | |
| dy | Amount to scroll in the Y direction. |
| void Gdk::Window::set_accept_focus | ( | bool | accept_focus = true |
) |
Setting accept_focus to false hints the desktop environment that the window doesn't want to receive input focus.
On X, it is the responsibility of the window manager to interpret this hint. ICCCM-compliant window manager usually respect it.
| accept_focus | true if the window should receive input focus. |
| void Gdk::Window::set_back_pixmap | ( | const Glib::RefPtr<Pixmap>& | pixmap, | |
| bool | parent_relative | |||
| ) |
Sets the background pixmap of window .
May also be used to set a background of "None" on window , by setting a background pixmap of 0. A background pixmap will be tiled, positioning the first tile at the origin of window , or if parent_relative is true, the tiling will be done based on the origin of the parent window (useful to align tiles in a parent with tiles in a child).
A background pixmap of 0 means that the window will have no background. A window with no background will never have its background filled by the windowing system, instead the window will contain whatever pixels were already in the corresponding area of the display.
The windowing system will normally fill a window with its background when the window is obscured then exposed, and when you call gdk_window_clear().
| pixmap | A Gdk::Pixmap, or 0. | |
| parent_relative | Whether the tiling origin is at the origin of window 's parent. |
| void Gdk::Window::set_background | ( | const Color& | color | ) |
Sets the background color of window .
(However, when using GTK+, set the background of a widget with gtk_widget_modify_bg() - if you're an application - or gtk_style_set_background() - if you're implementing a custom widget.)
The color must be allocated; gdk_rgb_find_color() is the best way to allocate a color.
See also gdk_window_set_back_pixmap().
| color | An allocated Gdk::Color. |
| void Gdk::Window::set_child_shapes | ( | ) |
Sets the shape mask of window to the union of shape masks for all children of window , ignoring the shape mask of window itself.
Contrast with gdk_window_merge_child_shapes() which includes the shape mask of window in the masks to be merged.
| void Gdk::Window::set_cursor | ( | ) |
Use the parent window's cursor.
For top-level windows this means that it will use the default cursor for the ROOT window.
| void Gdk::Window::set_cursor | ( | const Cursor& | cursor | ) |
Sets the mouse pointer for a Gdk::Window.
To make the cursor invisible, use gdk_cursor_new_from_pixmap() to create a cursor with no pixels in it.
| cursor | A cursor. |
| static void Gdk::Window::set_debug_updates | ( | bool | setting = true |
) | [static] |
With update debugging enabled, calls to gdk_window_invalidate_region() clear the invalidated region of the screen to a noticeable color, and GDK pauses for a short time before sending exposes to windows during gdk_window_process_updates().
The net effect is that you can see the invalid region for each window and watch redraws as they occur. This allows you to diagnose inefficiencies in your application.
In essence, because the GDK rendering model prevents all flicker, if you are redrawing the same region 400 times you may never notice, aside from noticing a speed problem. Enabling update debugging causes GTK to flicker slowly and noticeably, so you can see exactly what's being redrawn when, in what order.
The --gtk-debug=updates command line option passed to GTK+ programs enables this debug option at application startup time. That's usually more useful than calling gdk_window_set_debug_updates() yourself, though you might want to use this function to enable updates sometime after application startup time.
| setting | true to turn on update debugging. |
| void Gdk::Window::set_decorations | ( | WMDecoration | decorations | ) |
"Decorations" are the features the window manager adds to a toplevel Gdk::Window.
This function sets the traditional Motif window manager hints that tell the window manager which decorations you would like your window to have. Usually you should use gtk_window_set_decorated() on a Gtk::Window instead of using the GDK function directly.
The decorations argument is the logical OR of the fields in the Gdk::WMDecoration enumeration. If Gdk::DECOR_ALL is included in the mask, the other bits indicate which decorations should be turned off. If Gdk::DECOR_ALL is not included, then the other bits indicate which decorations should be turned on.
Most window managers honor a decorations hint of 0 to disable all decorations, but very few honor all possible combinations of bits.
| decorations | Decoration hint mask. |
| void Gdk::Window::set_events | ( | EventMask | event_mask | ) |
The event mask for a window determines which events will be reported for that window.
For example, an event mask including Gdk::BUTTON_PRESS_MASK means the window should report button press events. The event mask is the bitwise OR of values from the Gdk::EventMask enumeration.
| event_mask | Event mask for window . |
| void Gdk::Window::set_focus_on_map | ( | bool | focus_on_map | ) |
Setting focus_on_map to false hints the desktop environment that the window doesn't want to receive input focus when it is mapped.
focus_on_map should be turned off for windows that aren't triggered interactively (such as popups from network activity).
On X, it is the responsibility of the window manager to interpret this hint. Window managers following the freedesktop.org window manager extension specification should respect it.
| focus_on_map | true if the window should receive input focus when mapped. |
| void Gdk::Window::set_functions | ( | WMFunction | functions | ) |
This function isn't really good for much.
It sets the traditional Motif window manager hint for which operations the window manager should allow on a toplevel window. However, few window managers do anything reliable or interesting with this hint. Many ignore it entirely.
The functions argument is the logical OR of values from the Gdk::WMFunction enumeration. If the bitmask includes Gdk::FUNC_ALL, then the other bits indicate which functions to disable; if it doesn't include Gdk::FUNC_ALL, it indicates which functions to enable.
| functions | Bitmask of operations to allow on window . |
| void Gdk::Window::set_geometry_hints | ( | const Geometry& | geometry, | |
| WindowHints | geom_mask | |||
| ) |
Sets the geometry hints for window .
Hints flagged in geom_mask are set, hints not flagged in geom_mask are unset. To unset all hints, use a geom_mask of 0 and a geometry of 0.
This function provides hints to the windowing system about acceptable sizes for a toplevel window. The purpose of this is to constrain user resizing, but the windowing system will typically (but is not required to) also constrain the current size of the window to the provided values and constrain programatic resizing via gdk_window_resize() or gdk_window_move_resize().
Note that on X11, this effect has no effect on windows of type Gdk::WINDOW_TEMP or windows where override redirect has been turned on via gdk_window_set_override_redirect() since these windows are not resizable by the user.
Since you can't count on the windowing system doing the constraints for programmatic resizes, you should generally call gdk_window_constrain_size() yourself to determine appropriate sizes.
| geometry | Geometry hints. | |
| geom_mask | Bitmask indicating fields of geometry to pay attention to. |
| void Gdk::Window::set_group | ( | const Glib::RefPtr<Window>& | leader | ) |
Sets the group leader window for window .
By default, GDK sets the group leader for all toplevel windows to a global window implicitly created by GDK. With this function you can override this default.
The group leader window allows the window manager to distinguish all windows that belong to a single application. It may for example allow users to minimize/unminimize all windows belonging to an application at once. You should only set a non-default group window if your application pretends to be multiple applications.
| leader | Group leader window, or 0 to restore the default group leader window. |
| void Gdk::Window::set_icon | ( | const Glib::RefPtr<Window>& | icon_window, | |
| const Glib::RefPtr<Pixmap>& | pixmap | |||
| ) |
| void Gdk::Window::set_icon | ( | const Glib::RefPtr<Window>& | icon_window, | |
| const Glib::RefPtr<Pixmap>& | pixmap, | |||
| const Glib::RefPtr<Bitmap>& | mask | |||
| ) |
Sets the icon of window as a pixmap or window.
If using GTK+, investigate gtk_window_set_default_icon_list() first, and then gtk_window_set_icon_list() and gtk_window_set_icon(). If those don't meet your needs, look at gdk_window_set_icon_list(). Only if all those are too high-level do you want to fall back to gdk_window_set_icon().
| icon_window | A Gdk::Window to use for the icon. | |
| pixmap | A Gdk::Pixmap to use as the icon,. | |
| mask | A 1-bit pixmap (Gdk::Bitmap) to use as mask for pixmap . |
| void Gdk::Window::set_icon_list | ( | const Glib::ListHandle<Glib::RefPtr<Gdk::Pixbuf>>& | pixbufs | ) |
Sets a list of icons for the window.
One of these will be used to represent the window when it has been iconified. The icon is usually shown in an icon box or some sort of task bar. Which icon size is shown depends on the window manager. The window manager can scale the icon but setting several size icons can give better image quality since the window manager may only need to scale the icon by a small amount or not at all.
| pixbufs | A list of pixbufs, of different sizes. |
| void Gdk::Window::set_icon_name | ( | const Glib::ustring & | name | ) |
Windows may have a name used while minimized, distinct from the name they display in their titlebar.
Most of the time this is a bad idea from a user interface standpoint. But you can set such a name with this function, if you like.
| name | Name of window while iconified (minimized). |
| void Gdk::Window::set_keep_above | ( | bool | setting = true |
) |
Set if window must be kept above other windows.
If the window was already above, then this function does nothing.
On X11, asks the window manager to keep window above, if the window manager supports this operation. Not all window managers support this, and some deliberately ignore it or don't have a concept of "keep above"; so you can't rely on the window being kept above. But it will happen with most standard window managers, and GDK makes a best effort to get it to happen.
| setting | Whether to keep window above other windows. |
| void Gdk::Window::set_keep_below | ( | bool | setting = true |
) |
Set if window must be kept below other windows.
If the window was already below, then this function does nothing.
On X11, asks the window manager to keep window below, if the window manager supports this operation. Not all window managers support this, and some deliberately ignore it or don't have a concept of "keep below"; so you can't rely on the window being kept below. But it will happen with most standard window managers, and GDK makes a best effort to get it to happen.
| setting | Whether to keep window below other windows. |
| void Gdk::Window::set_modal_hint | ( | bool | modal = true |
) |
The application can use this hint to tell the window manager that a certain window has modal behaviour.
The window manager can use this information to handle modal windows in a special way.
You should only use this on windows for which you have previously called gdk_window_set_transient_for()
| modal | true if the window is modal, false otherwise. |
| void Gdk::Window::set_override_redirect | ( | bool | override_redirect = true |
) |
An override redirect window is not under the control of the window manager.
This means it won't have a titlebar, won't be minimizable, etc. - it will be entirely under the control of the application. The window manager can't see the override redirect window at all.
Override redirect should only be used for short-lived temporary windows, such as popup menus. Gtk::Menu uses an override redirect window in its implementation, for example.
| override_redirect | true if window should be override redirect. |
| void Gdk::Window::set_role | ( | const Glib::ustring & | role | ) |
When using GTK+, typically you should use gtk_window_set_role() instead of this low-level function.
The window manager and session manager use a window's role to distinguish it from other kinds of window in the same application. When an application is restarted after being saved in a previous session, all windows with the same title and role are treated as interchangeable. So if you have two windows with the same title that should be distinguished for session management purposes, you should set the role on those windows. It doesn't matter what string you use for the role, as long as you have a different role for each non-interchangeable kind of window.
| role | A string indicating its role. |
| void Gdk::Window::set_skip_pager_hint | ( | bool | skips_pager = true |
) |
Toggles whether a window should appear in a pager (workspace switcher, or other desktop utility program that displays a small thumbnail representation of the windows on the desktop).
If a window's semantic type as specified with gdk_window_set_type_hint() already fully describes the window, this function should not be called in addition, instead you should allow the window to be treated according to standard policy for its semantic type.
| skips_pager | true to skip the pager. |
| void Gdk::Window::set_skip_taskbar_hint | ( | bool | skips_taskbar = true |
) |
Toggles whether a window should appear in a task list or window list.
If a window's semantic type as specified with gdk_window_set_type_hint() already fully describes the window, this function should not be called in addition, instead you should allow the window to be treated according to standard policy for its semantic type.
| skips_taskbar | true to skip the taskbar. |
| static void Gdk::Window::set_sm_client_id | ( | const Glib::ustring & | sm_client_id | ) | [static] |
Sets the SM_CLIENT_ID property on the application's leader window so that the window manager can save the application's state using the X11R6 ICCCM session management protocol.
See the X Session Management Library documentation for more information on session management and the Inter-Client Communication Conventions Manual (ICCCM) for information on the WM_CLIENT_LEADER property. (Both documents are part of the X Window System distribution.)
| sm_client_id | The client id assigned by the session manager when the connection was opened. |
| bool Gdk::Window::set_static_gravities | ( | bool | use_static = true |
) |
Set the bit gravity of the given window to static, and flag it so all children get static subwindow gravity.
This is used if you are implementing scary features that involve deep knowledge of the windowing system. Don't worry about it unless you have to.
| use_static | true to turn on static gravity. |
true if the server supports static gravity. | void Gdk::Window::set_title | ( | const Glib::ustring & | title | ) |
Sets the title of a toplevel window, to be displayed in the titlebar.
If you haven't explicitly set the icon name for the window (using gdk_window_set_icon_name()), the icon name will be set to title as well. title must be in UTF-8 encoding (as with all user-readable strings in GDK/GTK+). title may not be 0.
| title | Title of window . |
| void Gdk::Window::set_transient_for | ( | const Glib::RefPtr<Window>& | parent | ) |
Indicates to the window manager that window is a transient dialog associated with the application window parent .
This allows the window manager to do things like center window on parent and keep window above parent .
See gtk_window_set_transient_for() if you're using Gtk::Window or Gtk::Dialog.
| parent | Another toplevel Gdk::Window. |
| void Gdk::Window::set_type_hint | ( | WindowTypeHint | hint | ) |
The application can use this call to provide a hint to the window manager about the functionality of a window.
The window manager can use this information when determining the decoration and behaviour of the window.
The hint must be set before the window is mapped.
| hint | A hint of the function this window will have. |
| void Gdk::Window::set_urgency_hint | ( | bool | urgent = true |
) |
Toggles whether a window needs the user's urgent attention.
| urgent | true if the window is urgent. |
| void Gdk::Window::set_user_data | ( | gpointer | user_data | ) |
For most purposes this function is deprecated in favor of Glib::object_set_data().
However, for historical reasons GTK+ stores the Gtk::Widget that owns a Gdk::Window as user data on the Gdk::Window. So, custom widget implementations should use this function for that. If GTK+ receives an event for a Gdk::Window, and the user data for the window is non-0, GTK+ will assume the user data is a Gtk::Widget, and forward the event to that widget.
| user_data | User data. |
| void Gdk::Window::shape_combine_mask | ( | const Glib::RefPtr<Bitmap>& | mask, | |
| int | x, | |||
| int | y | |||
| ) |
Applies a shape mask to window .
Pixels in window corresponding to set bits in the mask will be visible; pixels in window corresponding to unset bits in the mask will be transparent. This gives a non-rectangular window.
If mask is 0, the shape mask will be unset, and the x / y parameters are not used.
On the X11 platform, this uses an X server extension which is widely available on most common platforms, but not available on very old X servers, and occasionally the implementation will be buggy. On servers without the shape extension, this function will do nothing.
This function works on both toplevel and child windows.
| mask | Shape mask. | |
| x | X position of shape mask with respect to window . | |
| y | Y position of shape mask with respect to window . |
| void Gdk::Window::shape_combine_region | ( | const Region& | shape_region, | |
| int | offset_x, | |||
| int | offset_y | |||
| ) |
Makes pixels in window outside shape_region be transparent, so that the window may be nonrectangular.
See also gdk_window_shape_combine_mask() to use a bitmap as the mask.
If shape_region is 0, the shape will be unset, so the whole window will be opaque again. offset_x and offset_y are ignored if shape_region is 0.
On the X11 platform, this uses an X server extension which is widely available on most common platforms, but not available on very old X servers, and occasionally the implementation will be buggy. On servers without the shape extension, this function will do nothing.
This function works on both toplevel and child windows.
| shape_region | Region of window to be non-transparent. | |
| offset_x | X position of shape_region in window coordinates. | |
| offset_y | Y position of shape_region in window coordinates. |
| void Gdk::Window::show | ( | ) |
Like gdk_window_show_unraised(), but also raises the window to the top of the window stack (moves the window to the front of the Z-order).
This function maps a window so it's visible onscreen. Its opposite is gdk_window_hide().
When implementing a Gtk::Widget, you should call this function on the widget's Gdk::Window as part of the "map" method.
| void Gdk::Window::show_unraised | ( | ) |
Shows a Gdk::Window onscreen, but does not modify its stacking order.
In contrast, gdk_window_show() will raise the window to the top of the window stack.
On the X11 platform, in Xlib terms, this function calls XMapWindow() (it also updates some internal GDK state, which means that you can't really use XMapWindow() directly on a GDK window).
| void Gdk::Window::stick | ( | ) |
"Pins" a window such that it's on all workspaces and does not scroll with viewports, for window managers that have scrollable viewports.
(When using Gtk::Window, gtk_window_stick() may be more useful.)
On the X11 platform, this function depends on window manager support, so may have no effect with many window managers. However, GDK will do the best it can to convince the window manager to stick the window. For window managers that don't support this operation, there's nothing you can do to force it to happen.
| void Gdk::Window::thaw_updates | ( | ) |
Thaws a window frozen with Gdk::Window::freeze_updates().
| void Gdk::Window::unfullscreen | ( | ) |
Moves the window out of fullscreen mode.
If the window was not fullscreen, does nothing.
On X11, asks the window manager to move window out of the fullscreen state, if the window manager supports this operation. Not all window managers support this, and some deliberately ignore it or don't have a concept of "fullscreen"; so you can't rely on the unfullscreenification actually happening. But it will happen with most standard window managers, and GDK makes a best effort to get it to happen.
| void Gdk::Window::unmaximize | ( | ) |
Unmaximizes the window.
If the window wasn't maximized, then this function does nothing.
On X11, asks the window manager to unmaximize window , if the window manager supports this operation. Not all window managers support this, and some deliberately ignore it or don't have a concept of "maximized"; so you can't rely on the unmaximization actually happening. But it will happen with most standard window managers, and GDK makes a best effort to get it to happen.
On Windows, reliably unmaximizes the window.
| void Gdk::Window::unset_icon | ( | ) |
| void Gdk::Window::unset_shape_combine_mask | ( | ) |
| static void Gdk::Window::unset_sm_client_id | ( | ) | [static] |
| void Gdk::Window::unstick | ( | ) |
Reverse operation for gdk_window_stick(); see gdk_window_stick(), and gtk_window_unstick().
| void Gdk::Window::withdraw | ( | ) |
Withdraws a window (unmaps it and asks the window manager to forget about it).
This function is not really useful as gdk_window_hide() automatically withdraws toplevel windows before hiding them.
| Glib::RefPtr<Gdk::Window> wrap | ( | GdkWindowObject * | object, | |
| bool | take_copy = false | |||
| ) | [related] |
A Glib::wrap() method for this object.
| object | The C instance. | |
| take_copy | False if the result should take ownership of the C instance. True if it should take a new copy or ref. |
